Product Information

KS KlipFix39 is the Concealed-fixed Roof System, (boltless system) – clip is fixed to the purlin before the sheet is located over clip. So, the fastener doesn’t pass through the sheet. Can be rolled-form on-site for long length roof without end lap or custom length as required. To increase roof drainage and waterproof, anti-leakage, suitable for roofing, walling and ceiling.

• Profile dimension : Cover width 700/ Rib height 39 mm
• Base metal Thickness (BMT) : 0.42, 0.45, 0.48, 0.55, 0.60 mm
• Zincalume (TCT) : 0.47, 0.50, 0.53, 0.60, 0.65 mm
• Strength of Steel : G550 Mpa (Min Yield strength 550 MPa)
• Coating : Zincalume and Colorbond steel
• Recommend min. roof slope : 2°
• Application : Straight, Curve, Roofing, Walling, Ceiling
• Method of installation : Boltless system (concealed-fixing)

Recommend for new clip “Clip-X-Fix”. There are 8 Highlights for good value and save cost.

1. 20% cheaper than the previous clip.
2. 20% faster installation to save cost
3. Save cost by reducing the Steel End Closer at the end of the sheet
4. Easier to install because have base alignment
5. Accurately installation with Stopper
6. Stronger, fully lock the sheet with the new clip with a specific design
7. Beautiful by reducing the little wave of sheet (Oilcanning)
8. Can be used with KS KlipFix39 and general boltless roof in the name “Kliplok”
